No reviews yet
Part Number:

Features:

  • For professional and semi-professional use.
  • Quiet, powerful inverter with 200 % peak power.
  • Compact, lightweight, and hum-free thanks to HF technology.
  • Pure sine wave voltage prevents malfunctions and damage to sensitive equipment such as adapters.
  • High yield and more power from your batteries.
  • Intelligent 3-step+ battery charger with low DC ripple current for fast charging times and long battery life.
  • Power Assist: prevents blown fuses.
  • A dynamic battery voltage window allows you to enjoy AC power for longer without damaging your batteries.
  • Active Optima Cooling concept prevents unnecessary fan noise.
  • Charges two individual battery banks simultaneously (Mass Combi Ultra).
  • An integrated MPPT solar charge controller allows for 30 % more yield from solar power for charging the batteries (Mass Combi Ultra).
  • Quick installation and reliable professional connections.
  • CE and ABYC certified.
SPECIFICATIONS
Part Number 8186311 8186315
Specifications Sine Wave Inverter
Nomimal DC voltage 12 V (9.5 – 16 V) 24 V (19 – 32 V)
Output Voltage 180-260 V, adjustable
Output Waveform True sine
Continous power at 40 °C, cos phi 1 3000 W 3500 W
Surge capability 6000 W 7000 W
Parallel Configuration
(For larger systems, an external transfer system is required)
Yes, up to 10 standard
3-Phase Configuration Yes, up to 3 x 3
Max. Efficiency ≥ 90 % ≥ 92 %
Energy Saving Mode Consumption 7 W
Specifications Battery Charger
Max. charge current at 40 °C 150 A at 14.25 V 100 A at 28.5V
Secondary Charger Output Voltage N/A
Secondary Charger Output Current N/A
Battery Temperature Sensor Yes, Included
Specifications Transfer System
AC Input (Generator) 50 A (switched)
AC Input (Mains) 30 A (switched)
AC Output 1 67 A
AC Output 2 50 A (switched)
Transfer Speed Seamless (< 1 ms)
Solar Input DC Specifications
Input Voltage Range N/A
Max. PV Peak Power N/A
Max. Input Current N/A
Max. Charge Current N/A
MPP Tracker N/A
General Specifications
Display/read-out LED display
Dimensions
(H x W x D)
472 x 318 x 178mm
(18.6 x 12.5 x 7 inch)
Weight 15.3 kg / 33.7lb
Approvals CE, E-mark, ABYC
Technical Specifications
Charge Characteristic IUoUo, Automatic 3-step+ for AGM/Gel/MLI/ Flooded/Traction/Spiral
Ground Relay Yes, Configurable
Temperature Range (Ambient Temp.) -25 °C to 60 °C, derating > 40 °C / -13 °F to 140 °F, derating > 104 °F
Cooling Vario Fan
Protection Degree IP23 (vertical mounting)
Protections Over-temperature, overload, short circuit, high/low battery voltage
MasterBus Compatible Yes
